What is CTCP Plate?

CTCP is the English abbreviation of Computer To Conventional Plate, which refers to computer-to-conventional plate making on traditional PS plates.The basic imaging principle of the plate and the light source have basically not changed. The only requirement is that the UV-Setter is configured in the system.

Most of the offset printing plates can be imaged using UV-Setter exposure. Just use digital micromirrors instead of film, and step-by-step seamless splicing area exposure to replace the one-time imaging of the entire format. It not only has the high quality and efficiency of CTP but also retains the characteristics of easy operation and stable performance when printing on traditional plates.

It uses ultraviolet light in the wavelength range of 360~450 to expose images on conventional plates, which inherits the advantages of CTP, such as timeliness and high quality, while effectively compensating for the cost disadvantages of the prepress reproduction process due to the use of dedicated CTP plates.

Technical Data Sheet

Plate type

CTCP Plate

Usage:

Offset Printing, Digital Printing

Style

Positive

Gauge:

0.15mm,0.20mm,0.25mm,0.30mm,0.40mm

Spectral sensitivity:

410nm

Exposure energy:

50 - 60 Mj/Cm2

Developing temperature:

23+/-2 degree

Resolution:

2~98% at 200lpi

Developing time:

30 - 40s

Run length:

50 000 - 100 000 impressions .

Shelf time:

18 months

Trademark:

HAOMEI or customized

Transportation Package:

Export standard, seaworthy package

Specification:

0.15mm 100PCS/box;0.25mm 50PCS/box;0.30mm 50PCS/box;
0.40mm 30 PCX/box; customized.

Origin:

China

HS code:

37013024
CTCP, Conventional Plate,offset printing plates, CTP plates
